Finite Element Modelling and Experimental Validation of CFRP-Strengthened Reinforced Concrete Beams

Yaman Al-Kamaki; Riadh Al-Mahaidi; Mand Askar; Razaq Ferhadi

Authors

Yaman Al-Kamaki Highway and Bridge Department, Technical College of Engineering, Duhok Polytechnic University (DPU)
Riadh Al-Mahaidi School of Engineering, Swinburne University of Technology, Hawthorn, Australia https://orcid.org/0000-0003-4456-6594
Mand Askar Highway and Bridge Department, Technical College of Engineering, Duhok Polytechnic University (DPU) https://orcid.org/0000-0002-8918-842X
Razaq Ferhadi College of Engineering, The American University of Kurdistan (AUK), Duhok, Kurdistan Region, Iraq https://orcid.org/0000-0002-9277-4120

Keywords:

reinforced concrete (RC) beams, Carbon fiber-reinforced polymer (CFRP), finite element models (FEMs), Strengthening, ATENA-GiD software

Abstract

Extreme loading and harsh environmental exposure are two of the many variables that can lead to reinforced concrete (RC) beam deterioration. Nowadays, the recommended technique for extending the life duration of degraded structures is the use of fiber-reinforced polymer (FRP) strengthening materials. FRP composites have been utilized to strengthen concrete members since the late 1970s in order to increase their ductility and load-bearing capability. Although FRP has been effectively utilized to repair concrete beams that have deteriorated due to both internal and external influences, the use of appropriate software limits the numerical modeling of Carbon Fiber-Reinforced Polymer (CFRP) for RC beam strengthening. To investigate the structural response, FEMs were developed in ATENA-GiD, aiming to clarify the behavior of both the control beams and those repaired with CFRP, and to assess their load-bearing capacity. This is a unique software that can be used only for RC elements. It can be stated from the experimental results taken from previously published work that the load-bearing capacity and deflection for the control beam were 47.7 kN and 35.7 mm, respectively. By adding one unidirectional CFRP sheet as U-wraps, the load increased and deflection decreased by 24.9 % and 48.2 %, respectively. When using the same test results for verification using FE software, the load-bearing capacity and deflection for the simulated model were 49.4 kN and 37.6 mm, respectively. When adding the CFRP sheet to the model, similar to that of experimental work done. After the analysis stage, the load increased and deflection decreased by 24.1 % and 52.1 %, respectively. This indicates that FRP has become a powerful composite material for strengthening existing RC structures.
